| Speaker |
|
| Speaker Unit |
6.5"*1 |
| Rated power |
20W/8Ω |
| Audio mode |
16 bit CD Sound Quality |
| Audio format |
MP3 |
| Voice |
|
| Voice codecs |
G.722.1, G.723.1, G.726, G.728, G.729 |
| Sampling rate |
8K ~ 16KHz |
| Signal to Noise Ratio |
>65dB |
| Harmonic Distortion |
≤1% |
| Network |
|
| Interface |
1* RJ45, 10BASE-T/100BASE-TX |
| Protocols |
SIP2.0(RFC3261),HTTP, TCP/IP, SSL, DNS, SNTP, NTP, RTSP, RTP, RTCP, TCP, UDP, MQTT, ICMP, IGMP, DHCP, ARP,Onvif |
| PoE |
Optional |
| VoIP |
Support SIP protocol for integration with VoIP systems, integrated with SIP PBX. |
| Physical |
|
| Power input |
DC 24V/2A |
| Material |
Plastic shell + aluminum mesh cover |
| Color |
White |
| Weight |
1.50KG |
| Size |
269x200x143mm |
| Power consumption |
≤30W |
| Stand-by power consumption |
≤3W |
| Protection circuit |
Overload, short circuit protection |
| Proof Level |
IP55 |
| Environmental |
|
| Operating temperature |
5℃～40℃ |
| Storage temperature |
0℃～40℃ |
| Humidity |
20% ~ 80% RH Non-condensing |
